MALABAR JR. (1939)
• Designed by John Alden
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
First Built:
1935
Number Built:
26
Dimensions
Length Overall (LOA):
9.55 m
Length Waterline (LWL):
6.73 m
Beam:
2.59 m
Draft (Max):
1.42 m
Weight & Ballast
Displacement:
4,536 kg
Ballast:
1,901 kg
Sail Plan
Foresail Area:
18.18 m²
Mainsail Area:
28.39 m²
Sail Area:
46.58 m²
Sail Area (reported):
46.45 m²
I (Fore Triangle Height):
9.68 m
J (Fore Triangle Base):
3.76 m
P (Mainsail Hoist):
11.18 m
E (Boom Length):
5.08 m
Est. Forestay Length:
10.38 m
Engine & Systems
Performance Ratios
Hull Speed:
6.30 knots
SA/Displacement (Calc):
17.34
SA/Displacement (Reported):
17.29
Ballast/Disp Ratio:
41.90%
Displacement/Length:
414.72
Comfort Ratio:
35.94
Capsize Screening:
1.58
S-Number:
1.07
Immersion:
120 kg/cm
Notes
There was actually a series of yachts known as MALABAR JR.'s beginning in 1926. The version shown here is the most popular, drawn by Carl Alberg (designed in 1939 #691) with 26 sisters built.
