LONGBOW 31 (WESTERLY)
Built by Westerly Marine Ltd. (UK)
• Designed by Laurent Giles
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1972
Last Built:
1980
Number Built:
265
Dimensions
Length Overall (LOA):
9.45 m
Length Waterline (LWL):
7.62 m
Beam:
2.90 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
4,264 kg
Ballast:
1,905 kg
Sail Plan
Foresail Area:
19.72 m²
Mainsail Area:
14.75 m²
Sail Area:
34.47 m²
Sail Area (reported):
34.47 m²
I (Fore Triangle Height):
11.58 m
J (Fore Triangle Base):
3.40 m
P (Mainsail Hoist):
9.68 m
E (Boom Length):
3.05 m
Est. Forestay Length:
12.07 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
MD2B
Engine Power:
25 HP
Fuel Capacity:
76 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
6.70 knots
SA/Displacement (Calc):
13.37
SA/Displacement (Reported):
13.37
Ballast/Disp Ratio:
44.68%
Displacement/Length:
268.57
Comfort Ratio:
27.02
Capsize Screening:
1.80
S-Number:
1.66
Immersion:
152 kg/cm
Notes
Aft cockpit. Same hull as BERWICK, PENTLAND & RENOWN.
