LANCER 28
Built by Lancer
• Designed by W. Shad Turner
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1977
Last Built:
1985
Dimensions
Length Overall (LOA):
8.43 m
Length Waterline (LWL):
7.29 m
Beam:
2.44 m
Draft (Max):
0.86 m
Headroom:
1.88 m
Weight & Ballast
Displacement:
2,223 kg
Ballast:
998 kg
Sail Plan
Foresail Area:
17.47 m²
Mainsail Area:
11.60 m²
Sail Area:
29.07 m²
Sail Area (reported):
28.71 m²
I (Fore Triangle Height):
9.75 m
J (Fore Triangle Base):
3.58 m
P (Mainsail Hoist):
8.23 m
E (Boom Length):
2.82 m
Est. Forestay Length:
10.39 m
Engine & Systems
Performance Ratios
Hull Speed:
6.55 knots
SA/Displacement (Calc):
17.40
SA/Displacement (Reported):
17.19
Ballast/Disp Ratio:
44.90%
Displacement/Length:
159.83
Comfort Ratio:
18.94
Capsize Screening:
1.89
S-Number:
3.28
Immersion:
122 kg/cm
Notes
Also available with a fractional rig stepped further forward.
