KELLS 23
Built by Kells Corp. (USA)
• Designed by Paul A. Lindh
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Swing Keel
Rigging Type:
Fractional Sloop
First Built:
1971
Last Built:
1980
Dimensions
Length Overall (LOA):
6.88 m
Length Waterline (LWL):
5.49 m
Beam:
2.36 m
Draft (Max):
1.52 m
Draft (Min):
0.28 m
Weight & Ballast
Displacement:
898 kg
Ballast:
238 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
9.24 m²
Mainsail Area:
9.27 m²
Sail Area:
18.51 m²
Sail Area (reported):
18.39 m²
I (Fore Triangle Height):
6.89 m
J (Fore Triangle Base):
2.68 m
P (Mainsail Hoist):
6.40 m
E (Boom Length):
2.90 m
Est. Forestay Length:
7.39 m
Engine & Systems
Performance Ratios
Hull Speed:
5.69 knots
SA/Displacement (Calc):
20.26
SA/Displacement (Reported):
20.14
Ballast/Disp Ratio:
26.52%
Displacement/Length:
151.57
Comfort Ratio:
10.32
Capsize Screening:
2.47
S-Number:
3.80
Immersion:
89 kg/cm
Notes
Sister to the The Kells 23, The Kells 23.5 has 0.5 ft more draft.
