KELLEY 24
Built by Intrepid Marine Services (USA)
• Designed by Bruce Kelley
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Lifting Keel
Rigging Type:
Masthead Sloop
First Built:
1978
Dimensions
Length Overall (LOA):
7.24 m
Length Waterline (LWL):
5.79 m
Beam:
2.81 m
Draft (Max):
1.52 m
Draft (Min):
0.33 m
Weight & Ballast
Displacement:
1,542 kg
Sail Plan
Foresail Area:
12.32 m²
Mainsail Area:
12.58 m²
Sail Area:
24.90 m²
Sail Area (reported):
24.90 m²
I (Fore Triangle Height):
9.08 m
J (Fore Triangle Base):
2.71 m
P (Mainsail Hoist):
8.02 m
E (Boom Length):
3.14 m
Est. Forestay Length:
9.48 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
19.02
SA/Displacement (Reported):
19.01
Displacement/Length:
221.29
Comfort Ratio:
13.36
Capsize Screening:
2.45
S-Number:
2.67
Immersion:
112 kg/cm
Notes
Designed to the MORC rule. (Prototype was called 'Toy'.)
