KAIULANI 38
Built by Kaiulani Sailing Vessels (USA)
• Designed by Ted Brewer
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
First Built:
1980
Dimensions
Length Overall (LOA):
11.58 m
Length Waterline (LWL):
9.55 m
Beam:
3.61 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
9,299 kg
Ballast:
3,357 kg
Sail Plan
Foresail Area:
38.95 m²
Mainsail Area:
30.30 m²
Sail Area:
69.26 m²
Sail Area (reported):
69.21 m²
I (Fore Triangle Height):
14.61 m
J (Fore Triangle Base):
5.33 m
P (Mainsail Hoist):
13.08 m
E (Boom Length):
4.63 m
Est. Forestay Length:
15.55 m
Engine & Systems
Performance Ratios
Hull Speed:
7.50 knots
SA/Displacement (Calc):
15.99
SA/Displacement (Reported):
15.98
Ballast/Disp Ratio:
36.10%
Displacement/Length:
297.59
Comfort Ratio:
35.39
Capsize Screening:
1.73
S-Number:
1.69
Immersion:
236 kg/cm
Notes
Ted Brewer design #161.
