J/34 C
Built by J Boats Tillotson Pearson (USA)
• Designed by Rodney S. Johnstone
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Wing Keel
Rigging Type:
Masthead Sloop
First Built:
1986
Last Built:
1990
Number Built:
36
Dimensions
Length Overall (LOA):
10.52 m
Length Waterline (LWL):
9.14 m
Beam:
3.38 m
Draft (Max):
1.49 m
Weight & Ballast
Displacement:
5,443 kg
Ballast:
2,041 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.66 m²
Mainsail Area:
28.22 m²
Sail Area:
56.88 m²
Sail Area (reported):
56.86 m²
I (Fore Triangle Height):
13.93 m
J (Fore Triangle Base):
4.11 m
P (Mainsail Hoist):
12.34 m
E (Boom Length):
4.57 m
Est. Forestay Length:
14.52 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Power:
28 HP
Performance Ratios
Hull Speed:
7.34 knots
SA/Displacement (Calc):
18.75
SA/Displacement (Reported):
18.75
Ballast/Disp Ratio:
37.50%
Displacement/Length:
198.41
Comfort Ratio:
23.97
Capsize Screening:
1.94
S-Number:
2.93
Immersion:
212 kg/cm
Notes
Features 'UFO' keel, which, according to the builder is 'part wing and part bulb'. Displacement was originally listed as 10,000 lb/ 4,536 kg.
