ISLANDER 40
Built by Islander Yachts (USA)
• Designed by Doug Peterson
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1979
Dimensions
Length Overall (LOA):
12.05 m
Length Waterline (LWL):
9.40 m
Beam:
3.61 m
Draft (Max):
2.19 m
Max Height:
17.68 m
Weight & Ballast
Displacement:
7,711 kg
Ballast:
3,493 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
40.62 m²
Mainsail Area:
27.58 m²
Sail Area:
68.20 m²
Sail Area (reported):
68.19 m²
I (Fore Triangle Height):
16.15 m
J (Fore Triangle Base):
5.03 m
P (Mainsail Hoist):
14.48 m
E (Boom Length):
3.81 m
Est. Forestay Length:
16.92 m
Engine & Systems
Engine Make:
Pathfinder
Engine Type:
Diesel
Engine Model:
50MF
Engine Power:
42 HP
Fuel Capacity:
132 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
7.44 knots
SA/Displacement (Calc):
17.83
SA/Displacement (Reported):
17.83
Ballast/Disp Ratio:
45.29%
Displacement/Length:
258.99
Comfort Ratio:
29.25
Capsize Screening:
1.84
S-Number:
2.16
Immersion:
233 kg/cm
Notes
Shoal draft 'Sheel' keel version also available, usually with a shorter rig (SA = 705 sqft).
