ISLAND PACKET 485/525
Built by Island Packet Yachts (USA)
• Designed by Bob Johnson
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long keel w/rudder on skeg
Rigging Type:
Cutter
First Built:
2002
Dimensions
Length Overall (LOA):
15.90 m
Length Waterline (LWL):
13.16 m
Beam:
4.67 m
Draft (Max):
1.60 m
Max Height:
19.35 m
Weight & Ballast
Displacement:
20,026 kg
Ballast:
7,257 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
53.67 m²
Mainsail Area:
44.61 m²
Sail Area:
98.28 m²
Sail Area (reported):
114.64 m²
I (Fore Triangle Height):
18.06 m
J (Fore Triangle Base):
5.94 m
P (Mainsail Hoist):
15.01 m
E (Boom Length):
5.94 m
Est. Forestay Length:
19.01 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
4JK4-HTBE
Engine Power:
110 HP
Fuel Capacity:
1,136 L
Water Capacity:
1,136 L
Performance Ratios
Hull Speed:
8.80 knots
SA/Displacement (Calc):
13.61
SA/Displacement (Reported):
15.87
Ballast/Disp Ratio:
36.24%
Displacement/Length:
244.98
Comfort Ratio:
39.24
Capsize Screening:
1.74
S-Number:
1.87
Immersion:
422 kg/cm
Notes
IP 485 renamed the IP 525.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
