INTRO 22
Built by Seaglass (UK)
• Designed by David Thomas
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
First Built:
1975
Dimensions
Length Overall (LOA):
6.63 m
Length Waterline (LWL):
5.56 m
Beam:
2.79 m
Draft (Max):
1.40 m
Weight & Ballast
Displacement:
1,270 kg
Ballast:
544 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
10.66 m²
Mainsail Area:
9.78 m²
Sail Area:
20.44 m²
Sail Area (reported):
25.92 m²
I (Fore Triangle Height):
8.23 m
J (Fore Triangle Base):
2.59 m
P (Mainsail Hoist):
8.23 m
E (Boom Length):
2.38 m
SPL/TPS:
2.74 m
ISP:
8.23 m
Est. Forestay Length:
8.63 m
Engine & Systems
Performance Ratios
Hull Speed:
5.72 knots
SA/Displacement (Calc):
17.77
SA/Displacement (Reported):
22.53
Ballast/Disp Ratio:
42.86%
Displacement/Length:
205.98
Comfort Ratio:
11.74
Capsize Screening:
2.60
S-Number:
2.72
Immersion:
107 kg/cm
Notes
Originally designed to be built of plywood (multi-chine) by individuals. Later built of FG. Thanks to INTRO 22 owner Nick Jaguar for supplying images and information.
