IMX-40
Built by X Yachts
• Designed by Niels Jeppesen
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
2000
Last Built:
2004
Number Built:
99
Dimensions
Length Overall (LOA):
12.10 m
Length Waterline (LWL):
10.45 m
Beam:
3.80 m
Draft (Max):
2.45 m
Weight & Ballast
Displacement:
6,800 kg
Ballast:
2,400 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
36.01 m²
Mainsail Area:
41.89 m²
Sail Area:
77.90 m²
Sail Area (reported):
77.95 m²
I (Fore Triangle Height):
16.01 m
J (Fore Triangle Base):
4.50 m
P (Mainsail Hoist):
15.20 m
E (Boom Length):
5.51 m
Est. Forestay Length:
16.63 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD 2040-S
Engine Power:
40 HP
Performance Ratios
Hull Speed:
7.85 knots
SA/Displacement (Calc):
22.15
SA/Displacement (Reported):
22.16
Ballast/Disp Ratio:
35.29%
Displacement/Length:
166.13
Comfort Ratio:
22.40
Capsize Screening:
2.03
S-Number:
3.79
Immersion:
273 kg/cm
Notes
Later became X-40 (2004).
