C&C 30-1 (1-506)
Built by C&C Yachts (CAN)
• Designed by C&C
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1973
Last Built:
1985
Number Built:
800
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
7.60 m
Beam:
3.05 m
Draft (Max):
1.52 m
Headroom:
1.85 m
Max Height:
12.95 m
Weight & Ballast
Displacement:
3,629 kg
Ballast:
1,565 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
24.46 m²
Mainsail Area:
18.16 m²
Total Sail Area (calculated):
42.62 m²
Sail Area (reported):
42.64 m²
I (Fore Triangle Height):
11.89 m
J (Fore Triangle Base):
4.11 m
P (Mainsail Hoist):
10.36 m
E (Boom Length):
3.51 m
Engine & Systems
Engine Make:
various
Fuel Capacity:
76 L
Water Capacity:
159 L
Performance Ratios
Hull Speed:
6.69 knots
SA/Displacement (Calculated):
18.05
SA/Displacement (Reported):
18.42
Ballast/Disp Ratio:
43.13%
Displacement/Length:
230.78
Comfort Ratio:
21.77
Capsize Screening:
2.00
S-Number:
2.51
Notes
Design # 70-14 (14th project in 1970). The C&C 30 Mk1, was in production for more than 12 years, longer than any other C&C model.
