HUMBOLDT 30
Built by Humboldt Bay Yachts (USA)
• Designed by Gary Mull/Jim Donovan
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
First Built:
1982
Last Built:
1984
Number Built:
6
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
8.13 m
Beam:
3.20 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
2,291 kg
Ballast:
1,008 kg
Sail Plan
Foresail Area:
20.03 m²
Mainsail Area:
26.60 m²
Sail Area:
46.64 m²
Sail Area (reported):
46.64 m²
I (Fore Triangle Height):
11.43 m
J (Fore Triangle Base):
3.51 m
P (Mainsail Hoist):
12.65 m
E (Boom Length):
4.21 m
Est. Forestay Length:
11.95 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
1GM
Engine Power:
10 HP
Fuel Capacity:
19 L
Water Capacity:
30 L
Performance Ratios
Hull Speed:
6.92 knots
SA/Displacement (Calc):
27.37
SA/Displacement (Reported):
27.37
Ballast/Disp Ratio:
44.00%
Displacement/Length:
118.84
Comfort Ratio:
12.31
Capsize Screening:
2.45
S-Number:
5.37
Immersion:
179 kg/cm
Notes
Also called HUMBOLT BAY 30.
