HORIZON 26 (PAYNE)
Built by Horizon Yacht Marine (USA)
• Designed by Alan Payne
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1976
Dimensions
Length Overall (LOA):
7.87 m
Length Waterline (LWL):
6.96 m
Beam:
2.44 m
Draft (Max):
0.63 m
Weight & Ballast
Displacement:
1,996 kg
Ballast:
635 kg
Sail Plan
Foresail Area:
12.83 m²
Mainsail Area:
12.18 m²
Sail Area:
25.02 m²
Sail Area (reported):
26.01 m²
I (Fore Triangle Height):
8.94 m
J (Fore Triangle Base):
2.87 m
P (Mainsail Hoist):
7.67 m
E (Boom Length):
3.18 m
Est. Forestay Length:
9.39 m
Engine & Systems
Performance Ratios
Hull Speed:
6.40 knots
SA/Displacement (Calc):
16.09
SA/Displacement (Reported):
16.73
Ballast/Disp Ratio:
31.82%
Displacement/Length:
165.08
Comfort Ratio:
17.95
Capsize Screening:
1.96
S-Number:
3.03
Immersion:
117 kg/cm
Notes
Simlar to the COLUMBIA T-26. Another later version is the COMMODORE 26.
