HM-27
Built by DS Yachts (CAN)
• Designed by Ted Brewer/Robert Walstrom
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1975
Dimensions
Length Overall (LOA):
8.31 m
Length Waterline (LWL):
6.55 m
Beam:
2.82 m
Draft (Max):
1.30 m
Weight & Ballast
Displacement:
3,357 kg
Ballast:
1,370 kg
Sail Plan
Foresail Area:
19.60 m²
Mainsail Area:
17.36 m²
Sail Area:
36.96 m²
Sail Area (reported):
36.98 m²
I (Fore Triangle Height):
11.43 m
J (Fore Triangle Base):
3.43 m
P (Mainsail Hoist):
9.91 m
E (Boom Length):
3.51 m
Est. Forestay Length:
11.93 m
Engine & Systems
Performance Ratios
Hull Speed:
6.21 knots
SA/Displacement (Calc):
16.81
SA/Displacement (Reported):
16.82
Ballast/Disp Ratio:
40.81%
Displacement/Length:
332.41
Comfort Ratio:
25.43
Capsize Screening:
1.90
S-Number:
1.50
Immersion:
127 kg/cm
Notes
Also known as the HULLMASTER 27.
