H22
Built by Lion Yacht (LATVIA)
• Designed by Robert Humphreys
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
First Built:
1994
Dimensions
Length Overall (LOA):
6.70 m
Length Waterline (LWL):
6.10 m
Beam:
2.55 m
Draft (Max):
1.50 m
Draft (Min):
0.46 m
Weight & Ballast
Displacement:
770 kg
Ballast:
315 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
10.26 m²
Mainsail Area:
15.75 m²
Sail Area:
26.01 m²
Sail Area (reported):
30.47 m²
I (Fore Triangle Height):
7.80 m
J (Fore Triangle Base):
2.63 m
P (Mainsail Hoist):
9.00 m
E (Boom Length):
3.50 m
Est. Forestay Length:
8.23 m
Engine & Systems
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calc):
31.54
SA/Displacement (Reported):
36.95
Ballast/Disp Ratio:
40.87%
Displacement/Length:
94.61
Comfort Ratio:
7.51
Capsize Screening:
2.81
S-Number:
6.54
Immersion:
107 kg/cm
Notes
Initially designed as a kit boat for amateur builders using the 'Prefix' build system, (glass moldings with pre-cut plywood panels).
