H-35
Built by Artekno (FIN)
• Designed by Hans Groop
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Fractional Sloop
First Built:
1975
Last Built:
1986
Number Built:
280
Dimensions
Length Overall (LOA):
10.67 m
Length Waterline (LWL):
8.10 m
Beam:
2.60 m
Draft (Max):
1.50 m
Weight & Ballast
Displacement:
3,500 kg
Ballast:
1,520 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
17.74 m²
Mainsail Area:
18.56 m²
Sail Area:
36.30 m²
Sail Area (reported):
36.33 m²
I (Fore Triangle Height):
10.12 m
J (Fore Triangle Base):
3.51 m
P (Mainsail Hoist):
10.97 m
E (Boom Length):
3.38 m
Est. Forestay Length:
10.71 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
YS8M
Performance Ratios
Hull Speed:
6.91 knots
SA/Displacement (Calc):
16.06
SA/Displacement (Reported):
16.07
Ballast/Disp Ratio:
43.43%
Displacement/Length:
183.43
Comfort Ratio:
23.57
Capsize Screening:
1.73
S-Number:
2.79
Immersion:
145 kg/cm
