GRAND SURPISE
Built by Archambault Boats (FRA)
• Designed by Joubert / Nivelt
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
1999
Dimensions
Length Overall (LOA):
9.54 m
Length Waterline (LWL):
8.93 m
Beam:
2.98 m
Draft (Max):
2.05 m
Weight & Ballast
Displacement:
2,650 kg
Ballast:
1,050 kg
Sail Plan
Foresail Area:
20.94 m²
Mainsail Area:
29.58 m²
Sail Area:
50.52 m²
Sail Area (reported):
50.54 m²
I (Fore Triangle Height):
12.28 m
J (Fore Triangle Base):
3.41 m
P (Mainsail Hoist):
13.15 m
E (Boom Length):
4.50 m
Est. Forestay Length:
12.75 m
Engine & Systems
Engine Make:
Lombardini
Engine Type:
Diesel
Fuel Capacity:
26 L
Performance Ratios
Hull Speed:
7.25 knots
SA/Displacement (Calc):
26.90
SA/Displacement (Reported):
26.91
Ballast/Disp Ratio:
39.63%
Displacement/Length:
103.68
Comfort Ratio:
14.48
Capsize Screening:
2.18
S-Number:
5.67
Immersion:
183 kg/cm
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
