GIB'SEA 77
Built by Gilbert Marine (FRA)
• Designed by Groupe Graal/Jean-Claude Meyran
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1979
Last Built:
1984
Number Built:
224
Dimensions
Length Overall (LOA):
7.95 m
Length Waterline (LWL):
6.90 m
Beam:
2.80 m
Draft (Max):
1.77 m
Draft (Min):
0.87 m
Headroom:
1.75 m
Weight & Ballast
Displacement:
1,800 kg
Ballast:
735 kg
Ballast Type:
Iron
Sail Plan
Sail Area (reported):
34.85 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
1GM
Engine Power:
6.5 HP
Fuel Capacity:
25 L
Water Capacity:
80 L
Performance Ratios
Hull Speed:
6.38 knots
SA/Displacement (Reported):
24.01
Ballast/Disp Ratio:
40.83%
Displacement/Length:
152.65
Comfort Ratio:
13.50
Capsize Screening:
2.33
Immersion:
133 kg/cm
Notes
3 keel options were available: (fin, bilge and centreboard).
