GALION 22
Built by Robert Ives Boatbuilders Ltd. (UK)
• Designed by Ian Haney
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
1967
Dimensions
Length Overall (LOA):
6.71 m
Length Waterline (LWL):
5.49 m
Beam:
2.21 m
Draft (Max):
0.99 m
Headroom:
1.75 m
Weight & Ballast
Displacement:
1,588 kg
Ballast:
771 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
8.96 m²
Mainsail Area:
9.56 m²
Sail Area:
18.52 m²
Sail Area (reported):
18.49 m²
I (Fore Triangle Height):
6.78 m
J (Fore Triangle Base):
2.64 m
P (Mainsail Hoist):
6.97 m
E (Boom Length):
2.74 m
Est. Forestay Length:
7.28 m
Engine & Systems
Engine Make:
Renault
Engine Type:
Diesel
Engine Power:
6 HP
Fuel Capacity:
19 L
Water Capacity:
15 L
Performance Ratios
Hull Speed:
5.69 knots
SA/Displacement (Calc):
13.87
SA/Displacement (Reported):
13.85
Ballast/Disp Ratio:
48.57%
Displacement/Length:
267.92
Comfort Ratio:
20.12
Capsize Screening:
1.91
S-Number:
1.72
Immersion:
83 kg/cm
Notes
In 1968 a GALION 22 won both the Round the Island Race and the JOG Single-handed Race skippered by her designer, Ian Haney.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
