FREEDOM 40/40
Built by Tillotson Pearson Inc, (USA)
• Designed by David Pedrick
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Frac. Sloop (Free standing)
First Built:
1993
Dimensions
Length Overall (LOA):
12.32 m
Length Waterline (LWL):
10.69 m
Beam:
4.11 m
Draft (Max):
2.06 m
Max Height:
18.59 m
Weight & Ballast
Displacement:
10,756 kg
Ballast:
4,878 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.58 m²
Mainsail Area:
44.90 m²
Sail Area:
73.49 m²
Sail Area (reported):
73.49 m²
I (Fore Triangle Height):
14.55 m
J (Fore Triangle Base):
3.93 m
P (Mainsail Hoist):
15.63 m
E (Boom Length):
5.75 m
Est. Forestay Length:
15.07 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3JH2-TBE
Engine Power:
45 HP
Fuel Capacity:
235 L
Water Capacity:
401 L
Performance Ratios
Hull Speed:
7.94 knots
SA/Displacement (Calc):
15.39
SA/Displacement (Reported):
15.39
Ballast/Disp Ratio:
45.35%
Displacement/Length:
245.22
Comfort Ratio:
31.21
Capsize Screening:
1.88
S-Number:
2.06
Immersion:
302 kg/cm
Notes
Free-standing fractional sloop with self-tending 'Beirig' jib.
