FRANCES 26
Built by Morris Yachts (USA)/Victoria Marine(UK)
• Designed by Chuck Paine
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long Keel
Rigging Type:
Fractional Sloop
First Built:
1975
Number Built:
200
Dimensions
Length Overall (LOA):
7.92 m
Length Waterline (LWL):
6.48 m
Beam:
2.49 m
Draft (Max):
1.17 m
Headroom:
1.42 m
Weight & Ballast
Displacement:
3,084 kg
Ballast:
1,588 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
13.80 m²
Mainsail Area:
17.47 m²
Sail Area:
31.26 m²
Sail Area (reported):
31.31 m²
I (Fore Triangle Height):
9.45 m
J (Fore Triangle Base):
2.92 m
P (Mainsail Hoist):
9.75 m
E (Boom Length):
3.58 m
Est. Forestay Length:
9.89 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
1GM
Engine Power:
8 HP
Fuel Capacity:
57 L
Water Capacity:
57 L
Performance Ratios
Hull Speed:
6.18 knots
SA/Displacement (Calc):
15.05
SA/Displacement (Reported):
15.07
Ballast/Disp Ratio:
51.47%
Displacement/Length:
316.36
Comfort Ratio:
28.24
Capsize Screening:
1.73
S-Number:
1.48
Immersion:
111 kg/cm
Notes
Approximately 100 boats built by Morris Yachts, (USA).
