C&C 3/4 TON
Built by Bruckmann/C&C Yachts
• Designed by C&C
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1974
Last Built:
1974
Number Built:
15
Dimensions
Length Overall (LOA):
10.01 m
Length Waterline (LWL):
8.05 m
Beam:
3.20 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
4,445 kg
Ballast:
1,848 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
27.96 m²
Mainsail Area:
18.71 m²
Total Sail Area (calculated):
46.67 m²
Sail Area (reported):
46.64 m²
I (Fore Triangle Height):
13.11 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
11.37 m
E (Boom Length):
3.29 m
Engine & Systems
Performance Ratios
Hull Speed:
6.89 knots
SA/Displacement (Calculated):
17.27
SA/Displacement (Reported):
17.60
Ballast/Disp Ratio:
41.58%
Displacement/Length:
237.24
Comfort Ratio:
23.32
Capsize Screening:
1.97
S-Number:
2.36
Notes
The 'semi custom' C&C 3/4 TON was the first design by Rob Ball for C&C yachts. The hull and sailplan are the same as that of the slightly later production version of the C&C 33-1.
