FD 12
Built by Ta Yang (TAIWAN)
• Designed by Eva Hollmann
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
First Built:
1974
Last Built:
1985
Number Built:
25
Dimensions
Length Overall (LOA):
15.34 m
Length Waterline (LWL):
12.80 m
Beam:
4.34 m
Draft (Max):
1.98 m
Weight & Ballast
Displacement:
15,955 kg
Ballast:
6,509 kg
Sail Plan
Foresail Area:
61.78 m²
Mainsail Area:
39.21 m²
Sail Area:
100.99 m²
Sail Area (reported):
100.99 m²
I (Fore Triangle Height):
17.88 m
J (Fore Triangle Base):
6.91 m
P (Mainsail Hoist):
16.42 m
E (Boom Length):
4.78 m
Est. Forestay Length:
19.17 m
Engine & Systems
Engine Make:
Lehman
Engine Type:
Diesel
Engine Model:
4D61
Engine Power:
61 HP
Fuel Capacity:
852 L
Water Capacity:
719 L
Performance Ratios
Hull Speed:
8.68 knots
SA/Displacement (Calc):
16.27
SA/Displacement (Reported):
16.27
Ballast/Disp Ratio:
40.80%
Displacement/Length:
211.95
Comfort Ratio:
35.51
Capsize Screening:
1.74
S-Number:
2.49
Immersion:
382 kg/cm
Notes
The FD 12 (or FLYING DUTCHMAN 12) was imported into the USA by Willem Eickholt and Associates. some 25 FD-12s were built by the Ta Yang (Tayana) yard in Taiwan from the mid 70's to mid 80's.
