FAST PASSAGE 39
Built by Philbrooks Shipyard (CAN) /Tollycraft
• Designed by William Garden
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
First Built:
1976
Last Built:
1985
Number Built:
40
Dimensions
Length Overall (LOA):
12.04 m
Length Waterline (LWL):
10.21 m
Beam:
3.61 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
9,525 kg
Ballast:
3,402 kg
Sail Plan
Foresail Area:
42.64 m²
Mainsail Area:
31.62 m²
Sail Area:
74.27 m²
Sail Area (reported):
74.23 m²
I (Fore Triangle Height):
15.54 m
J (Fore Triangle Base):
5.49 m
P (Mainsail Hoist):
14.02 m
E (Boom Length):
4.51 m
Est. Forestay Length:
16.48 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4-108
Fuel Capacity:
201 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.76 knots
SA/Displacement (Calc):
16.87
SA/Displacement (Reported):
16.86
Ballast/Disp Ratio:
35.71%
Displacement/Length:
249.37
Comfort Ratio:
34.23
Capsize Screening:
1.72
S-Number:
2.17
Immersion:
253 kg/cm
Notes
Available as kits or factory finished (Philbrooks Shipyard). Philbrooks sold the mold to Tollycraft Corp. While it is widely believed Tollycraft built 4 boats, we've been told by someone familiar with the line that in fact, after 1982, 9 boats were built by Tollycraft Corp.
