FARR 40 ONE-DESIGN
Built by Carroll Marine & others by license
• Designed by Bruce Farr
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
1997
Dimensions
Length Overall (LOA):
12.41 m
Length Waterline (LWL):
10.75 m
Beam:
4.03 m
Draft (Max):
2.60 m
Weight & Ballast
Displacement:
4,945 kg
Ballast:
2,250 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
38.12 m²
Mainsail Area:
49.24 m²
Sail Area:
87.36 m²
Sail Area (reported):
102.84 m²
I (Fore Triangle Height):
16.20 m
J (Fore Triangle Base):
4.71 m
P (Mainsail Hoist):
16.70 m
E (Boom Length):
5.90 m
SPL/TPS:
5.20 m
ISP:
18.50 m
Est. Forestay Length:
16.87 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Fuel Capacity:
76 L
Water Capacity:
159 L
Performance Ratios
Hull Speed:
7.96 knots
SA/Displacement (Calc):
30.71
SA/Displacement (Reported):
36.15
Ballast/Disp Ratio:
45.50%
Displacement/Length:
110.93
Comfort Ratio:
14.66
Capsize Screening:
2.39
S-Number:
5.98
Immersion:
298 kg/cm
