ETCHELLS CLASS
Built by David Heritage Racing Yachts
• Designed by E. W. Etchells
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Fractional Sloop
First Built:
1966
Dimensions
Length Overall (LOA):
9.30 m
Length Waterline (LWL):
6.71 m
Beam:
2.13 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
1,508 kg
Ballast:
987 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
10.26 m²
Mainsail Area:
17.36 m²
Sail Area:
27.62 m²
Sail Area (reported):
27.96 m²
I (Fore Triangle Height):
8.41 m
J (Fore Triangle Base):
2.44 m
P (Mainsail Hoist):
9.91 m
E (Boom Length):
3.51 m
Est. Forestay Length:
8.76 m
Engine & Systems
Performance Ratios
Hull Speed:
6.29 knots
SA/Displacement (Calc):
21.41
SA/Displacement (Reported):
21.68
Ballast/Disp Ratio:
65.41%
Displacement/Length:
139.40
Comfort Ratio:
15.66
Capsize Screening:
1.88
S-Number:
4.16
Immersion:
98 kg/cm
Notes
Originally called the E22 or ETCHELLS 22. Renamed ETCHELLS CLASS in 1990.
