ESTUARY ONE-DESIGN (UK)
• Designed by Morgan-Giles
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Centerboard Dinghy
Rigging Type:
Fractional Sloop
First Built:
1911
Number Built:
115
Dimensions
Length Overall (LOA):
5.49 m
Length Waterline (LWL):
5.11 m
Beam:
1.83 m
Draft (Max):
0.91 m
Draft (Min):
0.27 m
Weight & Ballast
Displacement:
386 kg
Ballast:
91 kg
Sail Plan
Sail Area (reported):
19.51 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.48 knots
SA/Displacement (Reported):
37.51
Ballast/Disp Ratio:
23.53%
Displacement/Length:
80.75
Comfort Ratio:
7.05
Capsize Screening:
2.54
Immersion:
64 kg/cm
Notes
Originally commisioned by the Alexanra Yacht Club and the Essex Yacht Club in 1911 for sailing around the Thames estuary. (UK) It was somewhat eclipsed after WWI by a new but similar design which became the ESSEX ONE-DESIGN (1919, also by Morgan-Giles).
