ELLIOTT 770
Built by Elliott Marine
• Designed by Greg Elliott
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
First Built:
1994
Dimensions
Length Overall (LOA):
7.70 m
Length Waterline (LWL):
7.70 m
Beam:
2.50 m
Draft (Max):
1.75 m
Draft (Min):
0.48 m
Weight & Ballast
Displacement:
1,089 kg
Ballast:
350 kg
Sail Plan
Foresail Area:
11.95 m²
Mainsail Area:
18.58 m²
Sail Area:
30.53 m²
Sail Area (reported):
29.73 m²
I (Fore Triangle Height):
8.81 m
J (Fore Triangle Base):
2.71 m
P (Mainsail Hoist):
9.60 m
E (Boom Length):
3.87 m
Est. Forestay Length:
9.22 m
Engine & Systems
Performance Ratios
Hull Speed:
6.73 knots
SA/Displacement (Calc):
29.40
SA/Displacement (Reported):
28.63
Ballast/Disp Ratio:
32.17%
Displacement/Length:
66.48
Comfort Ratio:
8.90
Capsize Screening:
2.45
S-Number:
7.07
Immersion:
132 kg/cm
Notes
Also built in US by Holby Marine.
