EDEL 5 (540/545)
Built by Edel (FRA), Edel (CAN)
• Designed by Maurice Edel
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
First Built:
1974
Last Built:
1983
Number Built:
2500
Dimensions
Length Overall (LOA):
5.40 m
Length Waterline (LWL):
4.50 m
Beam:
2.44 m
Draft (Max):
0.70 m
Weight & Ballast
Displacement:
776 kg
Ballast:
150 kg
Sail Plan
Sail Area (reported):
15.05 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.15 knots
SA/Displacement (Reported):
18.16
Ballast/Disp Ratio:
19.35%
Displacement/Length:
238.03
Comfort Ratio:
10.59
Capsize Screening:
2.68
Immersion:
75 kg/cm
Notes
Called the EDEL 545 in France.
