DUFOUR 500 GRAND LARGE
Built by Dufour
• Designed by Umberto Felci
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
2011
Last Built:
2015
Number Built:
100
Dimensions
Length Overall (LOA):
15.10 m
Length Waterline (LWL):
13.67 m
Beam:
4.80 m
Draft (Max):
2.30 m
Weight & Ballast
Displacement:
15,245 kg
Ballast:
4,042 kg
Sail Plan
Foresail Area:
48.21 m²
Mainsail Area:
45.49 m²
Sail Area:
93.70 m²
Sail Area (reported):
100.71 m²
I (Fore Triangle Height):
17.25 m
J (Fore Triangle Base):
5.59 m
P (Mainsail Hoist):
16.25 m
E (Boom Length):
5.60 m
Est. Forestay Length:
18.13 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Power:
75 HP
Fuel Capacity:
500 L
Water Capacity:
719 L
Performance Ratios
Hull Speed:
8.97 knots
SA/Displacement (Calc):
15.56
SA/Displacement (Reported):
16.72
Ballast/Disp Ratio:
26.51%
Displacement/Length:
166.31
Comfort Ratio:
28.57
Capsize Screening:
1.96
S-Number:
2.93
Immersion:
451 kg/cm
Notes
Sail Area:
Estimated Market Value
$319,000
-
$319,000
USD
Limited reliability
Based on 1 price point
Adjusted for inflation and depreciation. Prices may vary by condition and location.
