DS-22
Built by Diller-Schwill (CAN)
• Designed by Bruce Kirby
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
First Built:
1983
Dimensions
Length Overall (LOA):
6.61 m
Length Waterline (LWL):
5.64 m
Beam:
2.44 m
Draft (Max):
1.37 m
Draft (Min):
0.61 m
Weight & Ballast
Displacement:
1,089 kg
Ballast:
404 kg
Sail Plan
Foresail Area:
11.66 m²
Mainsail Area:
8.26 m²
Sail Area:
19.92 m²
Sail Area (reported):
19.88 m²
I (Fore Triangle Height):
8.23 m
J (Fore Triangle Base):
2.83 m
P (Mainsail Hoist):
6.95 m
E (Boom Length):
2.38 m
Est. Forestay Length:
8.71 m
Engine & Systems
Performance Ratios
Hull Speed:
5.76 knots
SA/Displacement (Calc):
19.19
SA/Displacement (Reported):
19.15
Ballast/Disp Ratio:
37.08%
Displacement/Length:
169.22
Comfort Ratio:
11.95
Capsize Screening:
2.39
S-Number:
3.38
Immersion:
94 kg/cm
Notes
A boat nearly the same as this was originally sold as the VISION 660.
