DS-20
Built by Schwill Yachts Inc. (CAN)
• Designed by Diller & Schwill
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Swing Keel
Rigging Type:
Fractional Sloop
First Built:
1972
Last Built:
1983
Dimensions
Length Overall (LOA):
6.22 m
Length Waterline (LWL):
5.51 m
Beam:
2.31 m
Draft (Max):
1.22 m
Draft (Min):
0.56 m
Max Height:
8.53 m
Weight & Ballast
Displacement:
839 kg
Ballast:
295 kg
Sail Plan
Foresail Area:
6.86 m²
Mainsail Area:
8.90 m²
Sail Area:
15.76 m²
Sail Area (reported):
15.79 m²
I (Fore Triangle Height):
5.43 m
J (Fore Triangle Base):
2.53 m
P (Mainsail Hoist):
6.28 m
E (Boom Length):
2.83 m
Est. Forestay Length:
5.99 m
Engine & Systems
Water Capacity:
76 L
Performance Ratios
Hull Speed:
5.70 knots
SA/Displacement (Calc):
18.05
SA/Displacement (Reported):
18.09
Ballast/Disp Ratio:
35.14%
Displacement/Length:
139.97
Comfort Ratio:
10.25
Capsize Screening:
2.47
S-Number:
3.68
Immersion:
87 kg/cm
Notes
A Mark II version had more interior amenities.
