DRAGON (INT)
Built by Abbott Boats (CAN)
• Designed by Johann Anker
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin Keel
Rigging Type:
Fractional Sloop
First Built:
1928
Dimensions
Length Overall (LOA):
8.89 m
Length Waterline (LWL):
5.79 m
Beam:
1.96 m
Draft (Max):
1.19 m
Weight & Ballast
Displacement:
1,696 kg
Ballast:
998 kg
Sail Plan
Foresail Area:
8.19 m²
Mainsail Area:
18.39 m²
Sail Area:
26.58 m²
Sail Area (reported):
26.57 m²
I (Fore Triangle Height):
8.02 m
J (Fore Triangle Base):
2.04 m
P (Mainsail Hoist):
10.06 m
E (Boom Length):
3.66 m
Est. Forestay Length:
8.27 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
19.05
SA/Displacement (Reported):
19.04
Ballast/Disp Ratio:
58.82%
Displacement/Length:
243.42
Comfort Ratio:
22.00
Capsize Screening:
1.66
S-Number:
2.43
Immersion:
78 kg/cm
Notes
Following a competition organised by the Royal Yacht Club of Gothenburg, the Dragon was conceived as a "day boat" or small coastal cruising boat. Selected as the 3 man keelboat for the 1948 Olympic Games in London.
