CATALINA 316
Built by Catalina Yachts (USA)
• Designed by Gerry Douglas
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
2024
Dimensions
Length Overall (LOA):
10.06 m
Length on Deck (LOD):
9.45 m
Length Waterline (LWL):
8.08 m
Beam:
3.53 m
Draft (Max):
1.91 m
Max Height:
15.01 m
Weight & Ballast
Displacement:
5,443 kg
Ballast:
1,814 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
23.83 m²
Mainsail Area:
25.24 m²
Sail Area:
49.07 m²
Sail Area (reported):
54.72 m²
I (Fore Triangle Height):
13.03 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
12.27 m
E (Boom Length):
4.11 m
Est. Forestay Length:
13.53 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3YM20
Engine Power:
21 HP
Fuel Capacity:
95 L
Water Capacity:
132 L
Performance Ratios
Hull Speed:
6.90 knots
SA/Displacement (Calc):
16.18
SA/Displacement (Reported):
18.04
Ballast/Disp Ratio:
33.33%
Displacement/Length:
287.87
Comfort Ratio:
24.97
Capsize Screening:
2.03
S-Number:
1.78
Immersion:
196 kg/cm
Notes
Shoal bulb keel: Draft - 4.75 ft; Ballast - 4,400 lbs; Displacement - 12,400 lbs.
