1D 35
Built by Carroll Marine Ltd.(USA)
• Designed by Nelson/Marek
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1998
Last Built:
2001
Number Built:
48
Dimensions
Length Overall (LOA):
10.67 m
Length Waterline (LWL):
9.60 m
Beam:
3.28 m
Draft (Max):
2.31 m
Headroom:
1.62 m
Weight & Ballast
Displacement:
2,971 kg
Ballast:
1,145 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
24.56 m²
Mainsail Area:
38.34 m²
Total Sail Area (calculated):
62.90 m²
Sail Area (reported):
74.51 m²
I (Fore Triangle Height):
12.89 m
J (Fore Triangle Base):
3.81 m
P (Mainsail Hoist):
13.55 m
E (Boom Length):
5.66 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM20FC
Engine Power:
18.5 HP
Fuel Capacity:
45 L
Water Capacity:
159 L
Performance Ratios
Hull Speed:
7.52 knots
SA/Displacement (Calculated):
30.44
SA/Displacement (Reported):
36.77
Ballast/Disp Ratio:
38.55%
Displacement/Length:
93.55
Comfort Ratio:
13.15
Capsize Screening:
2.30
S-Number:
6.50
Notes
ONE-DESIGN 35.
